air to fuel gauge install

O

ofl0926

Member
can someone please tell me how to install this gauge. it is from autometer. it has one red cable. one black cable and one purple cable. i rather someone tell me than for me to go by trial and error. just try to help me out thanks.

There is no need to be an asshole, it's clear he already has the guage if you know how how to hook it up why not help him out? if you don't have anything helpful to say don't post in his thread!

I sick of this Bull****, STFU and help.. or just go away

Last edited:
lmao your post didnt help him any either so stfu lol

that guage is pretty much useless though. i agree with get a wideband, and try to sell the guage. its basically just a neat little light show.

Last edited:
i have the gauge and a safc...i am very pleased...try to search on google for write ups and installs i wasnt home when mines was installed

Universal wiring:
Red 12V+ From a Key on source
Black Chasis Ground

Purple O2 Sensor Signal

For the signal I usual goto the ECU just to keep wires out of the engine bay. So you need a Pinout and a soldering iron.

Hope that helps

Kenrik: You post is of no use. Manny stated his opinion. If you have a problem PM him or Report it. DO NOT go after him in a post. :rolleyes:

As for the A/F Gauge the only time they work is while cruising. On WOT the ECU goes into Open Loop and the sensor is of no use. Like everyone said a light show.

to make you happy kenny....IM SORRY OFL0926, DIDNT MEAN TO BE A ****, JUST SAYING U MIghT AS WELL USe YOUR MONEY SOMEWHERE ELSE, HAPPY KENRIK?!?!? At least you got the install.

ps if ofl had a problem with my post thats was SOOOO insulting, he should have let me know thru pm's, i woulda deleted it, no prob.

...the best a/f u can get!

thanks guys. and dont worry about the comments. i know the wideband is better but i got this really cheap. there is always room for upgrading later on.

thanks
